Feature
|
Input Side
|
||||||
|
Max. DC Input Power (kW)
|
9.1
|
9.8
|
10.4
|
11.7
|
13
|
13.7
|
|
Max. DC Input Voltage (V)
|
550
|
|||||
|
Start-up DC Input Voltage (V)
|
80
|
|||||
|
MPPT Operating Range (V)
|
70~500
|
|||||
|
Max. DC Input Current (A)
|
13+26
|
26+26
|
||||
|
Max. Short Circuit Current (A)
|
19.5+39
|
39+39
|
||||
|
No.of MPP Trackers
|
2
|
|||||
|
No.of Strings per MPP Tracker
|
1+2
|
2
|
||||
|
Output Side
|
||||||
|
Rated Output Power (kW)
|
7
|
7.5
|
8
|
9
|
10
|
10.5
|
|
Max. Active Power (kW)
|
7.7
|
8.25
|
8.8
|
9.9
|
11
|
11.55
|
|
Nominal Output Voltage / Range (V)
|
L/N/PE 220V/0.85Un-1.1Un, 230V/0.85Un-1.1Un (Optional)
|
|||||
|
Rated Grid Frequency (Hz)
|
50 / 60 (Optional)
|
|||||
|
Operating Phase
|
Single phase
|
|||||
|
Rated AC Grid Output Current (A)
|
30.4
|
32.6
|
34.8
|
39.1
|
43.5
|
45.7
|
|
Max. AC Output Current (A)
|
33.5
|
35.9
|
38.3
|
43
|
47.8
|
50.2
|
|
Output Power Factor
|
0.8 leading to 0.8 lagging
|
|||||
|
Grid Current THD
|
<3%
|
|||||
|
DC Injection Current (mA)
|
<0.5%
|
|||||
|
Grid Frequency Range
|
47~52 or 57~62 (Optional)
|
|||||
|
Efficiency
|
||||||
|
Max. Efficiency
|
97.7%
|
|||||
|
Euro Efficiency
|
97.5%
|
|||||
|
MPPT Efficiency
|
>99%
|
|||||
|
Protection
|
||||||
|
DC Reverse-Polarity Protection
|
Yes
|
|||||
|
AC Short Circuit Protection
|
Yes
|
|||||
|
AC Output Overcurrent Protection
|
Yes
|
|||||
|
Output Overvoltage Protection
|
Yes
|
|||||
|
Insulation Resistance Protection
|
Yes
|
|||||
|
Ground Fault Monitoring
|
Yes
|
|||||
|
Anti-islanding Protection
|
Yes
|
|||||
|
Temperature Protection
|
Yes
|
|||||
|
Integrated DC Switch
|
Yes
|
|||||
|
Remote software upload
|
Yes
|
|||||
|
Remote change of operating parameters
|
Yes
|
|||||
|
Surge protection
|
DC Type II / AC Type II
|
|||||
|
General Data
|
||||||
|
Size (mm)
|
330W×410H×198.5D
|
|||||
|
Weight (kg)
|
15.7
|
|||||
|
Topology
|
Transformerless
|
|||||
|
Internal Consumption
|
<1W (Night)
|
|||||
|
Running Temperature
|
-25~65℃, >45℃ derating
|
|||||
|
Ingress Protection
|
IP65
|
|||||
|
Noise Emission (Typical)
|
<35 dB
|
|||||
|
Cooling Concept
|
Natural cooling
|
|||||
|
Max. Operating Altitude Without Derating
|
2000m
|
|||||
|
Warranty
|
5 years
|
|||||
|
Grid Connection Standard
|
CEI 0-21, VDE-AR-N 4105, NRS 097, IEC 62116, IEC 61727, G99, G98, VDE 0126-1-1, RD 1699, C10-11
|
|||||
|
Operating Surroundings Humidity
|
0-100%
|
|||||
|
Safety EMC / Standard
|
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
|
|||||
|
Features
|
||||||
|
DC Connection
|
MC-4 mateable
|
|||||
|
AC Connection
|
IP65 rated plug
|
|||||
|
Display
|
LCD1602
|
|||||
|
Interface
|
RS485/RS232/Wifi/LAN
|
|||||
