Feature
|
Input Side
|
|||||||||
|
Max. DC Input Power (kW)
|
13
|
15.6
|
19.5
|
13 | 15.6 | 19.5 | 23.4 | 26 | 27.3 |
|
Max. DC Input Voltage (V)
|
800
|
||||||||
|
Start-up DC Input Voltage (V)
|
250
|
||||||||
|
MPPT Operating Range (V)
|
200-700
|
||||||||
|
Max. DC Input Current (A)
|
32+32 | 32+32 |
40+40
|
||||||
|
Max. Short Circuit Current (A)
|
48+48 |
48+48
|
60+60
|
||||||
|
No.of MPP Trackers
|
2
|
||||||||
|
No.of Strings per MPP Tracker
|
3+3
|
2+2 | 3+3 | ||||||
|
Output Side
|
|||||||||
|
Rated Output Power (kW)
|
10
|
12
|
15
|
10
|
12
|
15
|
18
|
20
|
21
|
|
Max. Active Power (kW)
|
11 | 13.2 | 16.5 | 10 |
12
|
15
|
18
|
20
|
21
|
|
Rated Output Voltage/Range (V)
|
3L/N/PE 127/220V
|
3L/N/PE 133/230V | |||||||
|
Rated Grid Frequency (Hz)
|
60Hz/55Hz-65Hz
|
50Hz/45Hz-55Hz | |||||||
|
Operating Phase
|
Three Phase
|
||||||||
|
Rated AC Grid Output Current (A)
|
26.2 | 31.5 | 39.4 | 25.1 | 30.1 | 37.6 | 45.2 |
50.2
|
52.7
|
|
Max. AC Output Current (A)
|
28.9 | 34.6 | 43.3 | 25.1 | 30.1 | 37.6 | 45.2 |
50.2
|
52.7
|
|
Output Power Factor
|
0.8 leading to 0.8 lagging
|
||||||||
|
Total Harmonics Current Distortion (THDi)
|
<3%
|
||||||||
|
DC Injection Current (mA)
|
<0.5%
|
||||||||
|
Efficiency
|
|||||||||
|
Max. Efficiency
|
98.6%
|
||||||||
|
Euro Efficiency
|
98%
|
||||||||
|
MPPT Efficiency
|
>99%
|
||||||||
|
Protection
|
|||||||||
|
DC Reverse-Polarity Protection
|
Yes
|
||||||||
|
AC Short Circuit Protection
|
Yes
|
||||||||
|
AC Output Overcurrent Protection
|
Yes
|
||||||||
|
Output Overvoltage Protection
|
Yes
|
||||||||
|
Insulation Resistance Protection
|
Yes
|
||||||||
|
Ground Fault Monitoring
|
Yes
|
||||||||
|
Anti-islanding Protection
|
Yes
|
||||||||
|
Temperature Protection
|
Yes
|
||||||||
|
Integrated DC Switch
|
Yes
|
||||||||
|
Remote Software Upload
|
Yes
|
||||||||
|
Remote Change of Operating Parameters
|
Yes
|
||||||||
|
Surge Protection
|
DC Type II / AC Type II
|
||||||||
|
General Data
|
|||||||||
|
Cabinet Size (WxHxD mm)
|
362*577*215 (Excluding Connectors and Brackets)
|
||||||||
|
Weight (kg)
|
23 | ||||||||
|
Topology
|
Transformerless
|
||||||||
|
Internal Consumption
|
<1W (Night)
|
||||||||
|
Running Temperature
|
-25-65℃, >45℃ Derating
|
||||||||
|
Ingress Protection
|
IP65
|
||||||||
|
Noise Emission (Typical)
|
≤40 dB
|
≤50 dB
|
|||||||
|
Cooling Concept
|
Smart Cooling
|
||||||||
|
Permissible Altitude (m)
|
2000
|
||||||||
|
Warranty
|
5 Years
|
||||||||
|
Grid Connection Standard
|
NBR 16149,NBR 16150,EN 50549,RD 140
|
||||||||
|
Operating Surroundings Humidity
|
0-100%
|
||||||||
|
Safety EMC / Standard
|
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
|
||||||||
|
Features
|
|||||||||
|
Display
|
LCD1602
|
||||||||
|
Interface
|
RS485/RS232/Wifi/LAN
|
||||||||
Certification
